Flame Retardant Polycarbonate
Product Details
| Type | Colors Description |
|---|---|
| Transparent | Clear, Bronze, Brown, Gary, Red, Lighter Blue, Lighter Green |
| Translucent | Black, Opal White, Blue, Green |
| Opaque | Black, Opal White, Yellow, Dark Blue, Red, Dark Grey, Dark Brown |
| Physical Property | Testing Method | Unit | Value |
|---|---|---|---|
| Specific Gravity | D-792 | g/cm3 | 1.2 |
| Coefficient of Linear Thermal Expansion | D-696 | mm/m °C | 0.065 |
| Thermal Conductivity | C-177 | W/m K | 0.21 |
| Tensile Strength at Yield | D-638 | Mpa or N/mm² | >60 |
| Tensile Strength at Break | D-638 | MPa or N/mm² | >65 |
| Elongation at Break | D-638 | % | >100 |
| Tensile Modulus of Elasticity | D-638 | MPa | 2400 |
| Flexural Strength | D-790 | MPa | 100 |
| Fire rating | UL 94 | / | V2/V0 |
| Fire rating | ASTM E84 | / | Class B or Class A |
| Light transmittance | D-1003 | % | From 80% to 91% |
The default third-party testing organization is SGS;
Flame retardant Polycarbonate Sheet Introduction
Flame Retardant Polycarbonate offers improved fire resistance and heat deflection characteristics over the standard polycarbonate sheet. It meets the flammability codes of the engineering industry, construction industry, and transportation industry, such as UL94, ASTM E84, GB/T2408-2008, UL723, etc. Some people call it Fire Resistant Polycarbonate and Fireproof Plastic.
NAILIPU is the code of NAILIPU Flame Retardant Polycarbonate Sheet, which offers high clarity and surface quality. It is virtually unbreakable with extremely high impact resistance. In the case of fire, flame retardants can reduce the growth of fire in a very short time. As the most popular fire-resistant plastic sheet, flame retardant polycarbonate is the right material for machine guards, industrial parts, electrical components, a wide variety of vehicles, train seats that is requiring flame retardance, and the most application in that glass used.
NAILIPU is a leading supplier of flame-retardant polycarbonate in China. Sometimes, we make flame-retardant polycarbonate with custom colors, such as grey, brown, black, red, etc.
| hickness (mm) | Width (mm) | Length (m) | Packaged as Panel | Packaged as Roll |
|---|---|---|---|---|
| 0.125mm | 1220 | 2.44, 400 | ok | ok |
| 0.175mm | 1220 | 2.44, 350 | ok | ok |
| 0.25mm | 1220 | 2.44, 300 | ok | ok |
| 0.375mm | 1220 | 2.44, 200 | ok | ok |
| 0.5mm | 1220 | 2.44, 150 | ok | ok |
| 0.75mm | 1220 | 2.44, 100 | ok | ok |
| 1mm, 1.5mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12, 30, 40 | ok | ok |
| 2mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12, 30 | ok | ok |
| 2.5mm, 3mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12, 20 | ok | ok |
| 4mm, 5mm, 6mm, 8mm, 10mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12 | ok | |
| 8mm, 10mm, 12mm, 15mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12 | ok | |
| 16mm, 18mm, 20mm | 1000, 1220, 2100 | 2.44, 5.8 | ok |
Polycarbonate skylight
Skylight roof panel
Transportation system
Aircraft interior component
Reliable Quality: We use advanced production equipment and a strict quality‑control system.
Large Capacity: Eight production lines give an annual output of 50 000 tons.
Proven Experience: We have more than twenty years of manufacturing and export history.
Responsive Service: Dedicated staff reply quickly and follow each order through delivery.
Warranty: We provide a five‑ to ten‑year product warranty.
Performance: Our sheets offer high impact resistance, good bendability, high light transmission, self‑extinguishing fire performance, low weight, sound insulation, anti‑drip surfaces, UV blocking, energy savings, and recyclability.
